Science multimeter (DEGI-MARU)

A05-7700-W0

[Product Description]

  • Science Multimeter has three modes: the first one is the meter mode displays measured voltage, current, or resistance on the screen, and the second one is the simple mini-oscilloscope mode, which graphs the waveform of voltage and sound on the screen.

  • The third one is PC-link mode. A new WEB application for Science Multimeter collects and displays the measured values or waveform graphs on your PC or tablet PC if the Science Multimeter connects to the PC by USB cable.

[Overall Advantages to Users]

  • The screen design of Science Multimeter is simply and clear for users which shows the measured value of voltage, current, resistance, their bar graph, and waveforms like an oscilloscope.

  • The WEB application is free software for any user and does not need installation into your PC or tablet PC. When Science Multimeter connects to your PC, it shows all data on its screen online.

Benefit

Specifications

Download

[Benefit-To teachers]

  • Science Multimeter can provide suitable measuring method (see below) for students depending on the topics or their level of experimental skills.
  • Digital meter mode (Voltage, Current, Resistance)
    Mini-oscilloscope mode (Voltage waveform, Sound waveform)
    WEB-link mode (Voltage, Current, Resistance and waveform)

[Benefit-To students]

  • Students can read and check the measured value when they want as the Science Multimeter has a small LCD display to show measured data or waveform.
  • When they use the WEB application, it gives them good analysis tools.
  • Measurement range:
    • Voltmeter: ±25.0V (with ±5.00V range switching 0N/OFF yesterday)
    • Ammeter: ±500mA, ±5.0A (with auto range switching)
    • Resistance meter: 50/500/5K/500K/5MΩ (auto range switching)
    • Waveform: Sound 0 to 15khz (10 steps of time, 8 steps of amplitude), Voltage ±25V (10 steps of time, 8 steps of amplitude)
  • Display modes: sound waveform, voltage waveform, ammeter, voltmeter, resistance meter
  • Functions: Pause function (in sound waveform and voltage waveform mode), auto power off
  • Power source: 2 AAA dry cell batteries (sold separately) Dimensions: 90 x 60 x 33 mm
  • Attachment: USB cable (for connection to dedicated application)
